  • Glass Wool blanket with aluminum foil
  • Centrifugal glass wool is a silk-like material made by fiberization of melted glass and then coating with thermosetting resin through centrifugal blowing process. By means of thermal setting, this material can be further processed into series of products for multiple purposes.





    It has excellent thermal insurance performance at both high and low temperature environment. It is mainly used for the separating wall in the high-grade building, ceiling, air conduit or inner wall of bellows for thermal insurance, or machine shops for noise absorption,or metal ceiling for control of moisture.















    *Glass wool blanket / rolls
    SPECIFICATION
    FACING MATERIAL ALUM.FOIL
    LENGTH 10000-30000mm
    WIDTH 1200mm ( 600mm and 400mm is available)
    THINKNESS  25-200mm
    DENSITY 10,16,20,32,40,48kg/m3 (10-50kg/m3)
    MAX TEMPERATURE 400~600C
    SPECIAL SPECIFICATION PRODUCTS CAN BE MADE ON REQUEST

    *Glass wool pipe
    SPECIFICATION
    DESCRIPTION GLASS WOOL PIPE
    DENSITY (48-80)kg/m3
    THICKNESS (25-90)mm
    DIAMETER (18-529)mm(3/4 inch to 21 inch)
    LENGTH 1000mm,1200mm
    FACING MATERIAL ALUM.FOIL
    PACKAGING
    1) NORMAL STANDARD PE+PP
    2) HEAT CONTRACTION SEALED PE+PP+PE
    3) COLOR BAG PE+(PP+PE)
    4) CUSTOMIZING
    TECHNICAL PARAMETERS
    CERTIFICATION CE
    AVERAGE FIBER DIA. ≤5 µm
    MOISTURE CONTENT 0.2% Max
    CONDUCTIVITY COEFFICIENT (0.035-0.040)w/m.k
    HYDROPHOBICITY ≥99%
    SLAG INCLUSION <0.3%
    HEAT RESISTANCE COEFFICIENT (1.16-2.56)m2.k/m
    SOUND INSULATION COEFFICIENT 500HZ 1.13-1.23
    1000HZ 1.08-1.05
    2000HZ 1.04-1.00
    NON INFLAMMABLE GRADE A
    FIRE RETARDANT YES
    NON CORROSIVE YES
    VERMIN PROOF YES
