  • PP Pro-enviroment Insulated Duct---Model¡¾ALPP-IND¡¿

  • Non-formaldehyde , ammonia, benzene etc harmful substance, no smell, no poison, not do harm to people' health, and not pollute the environment.

    Good insulation---heat insulated.

    No corrosive---not corrode the alu. pipe and metal parts.

    Durability---not decay, mildew, durability.

    Fire---resistance.

    Practicality: suitable for the densely-populated area (such as school, supermarket, office, stadium, theater, factory...) high requietment of the enviroment area, such as hospital, laboratory, howff, bus, train, broadcasting studio.

    PROPERTIES VALUE
    Diameter Range 75-750mm (3"-30")
    Temperature Range -30 ~ +140ºC
    Velocity Of Air Flow (MAX.) 30 m/s
    Working Pressure 2500 Pa
    Bending Radius 0.54*D+25MM
    Thickness Of Fiberglass Insulation 25MM
    Density Of Fiberglass Insulation 14~32KG/M3
    Standard Length 10M,5M etc

     NOTE: OTHER SIZES AND LENGHT ETC ARE AVAILABLE ON REQUEST.
